CC1310 CC1190 Module, +27dBm, N620PA

CC1310 CC1190 Module, +27dBm, N620PA

Frequency: 868MHz,915MHz
Output Power: +27 dBm
Size: 34x25x3mm
Brand: Coral RF
Modulation: FSK
Package: SMD
Model: N620PA

N620PA cc1310 and cc1190 moduleN620PA based on TI CC1310F128 and CC1190 chip, 868MHz and 915MHz band used.

The cc1310 and cc1190 modules have an output power of up to +27dBm and down to -112dBm sensitivity. AT command and WMbus support.

N620PA module integrates CC1310 and CC1190, the module has +27 dBm output power. The module sensitivity is -112 dBm at 50 kbps. And it has low cost, low power consumption and long distance. Designed by 4-layer board, 50Ω impedance matching and anti-interference, IoT, intelligent home, wireless meter reading, scientific research and medical treatment, and medium and long-distance wireless communication equipment.

N620PA leads most pins of CC1310 out for secondary development.

N620PA hardware is designed for maximum range, 1500 m + Range (Line of Sight) at 50kbps.

N620PA (CC1310) is suitable for free frequency band in EU and USA.

Module Support Wireless protocols

IEEE 802.15.4g, IPv6-enabled smart objects (6LoWPAN), MIOTY®, Wireless M-Bus, WiSUN®, KNX RF, Amazon Sidewalk, proprietary systems, SimpleLink™ TI 15.4 stack (Sub-1 GHz), and dynamic multiprotocol manager (DMM) driver.

ISM Frequency supported by N620PA module

770M band: 770 MHz to 780 MHz (China)

868M band: 868 MHz to 870 MHz (China, EU, USA), 888 MHz to 889 MHz (Australia)

915M band: 902 MHz to 928 MHz (USA)

N620PA module Parameters

RF InterfaceParameterIntroduce
Frequency860MHz-960MHzSupport ISM
Output Power+27dBmThe maximum power 500mW
Symbol Rate0.3-4000kbpsSoftware programming control
Deviation+/-10kHzAntenna interface

In clear and open environment, the antenna gain

is 3 dBi, the height above the ground is 2.5 meters,

and the air speed is 1.2 kbps.

Hardware parametersValueRemarks
Size32.8 x 24.6 x 3mm-
Antenna InterfaceIPEX, RF PIN-
Communication InterfaceUART, SPISoftware programming

Electrical ParametersMinimumTypicalMaximumRemarks
Emission Current
Instantaneous power consumption
Receiving Current
Sleep current
Software programming control
Working Temperature-30

N620PA's CC1190 control Logic

Download N620PA datasheet

N620PA Pinout Description

Pin    NumberfunctionPin    Numberfunction

N620PA Package

N620PA package

CC1310 Description

The CC1310 device is a cost-effective, ultra-low-power, Sub-1 GHz RF device from Texas Instruments™ that is part of the SimpleLink microcontroller (MCU) platform. These devices all share a common, easy-to-use development environment with a single core software development kit (SDK) and a rich tool set. A one-time integration of the SimpleLink platform enables users to add any combination of devices from the portfolio into their design, allowing 100 percent code reuse when design requirements change. For more information, visit

With very low active RF and MCU current consumption, in addition to flexible low-power modes, the CC1310 device provides excellent battery life and allows long-range operation on small coin-cell batteries and in energy harvesting applications.

The CC1310 device combines a flexible, very low-power RF transceiver with a powerful 48-MHz Arm® Cortex®-M3 microcontroller in a platform supporting multiple physical layers and RF standards. A dedicated Radio Controller (Cortex®-M0) handles low-level RF protocol commands that are stored in ROM or RAM, thus ensuring ultra-low power and flexibility. The low-power consumption of the CC1310 device does not come at the expense of RF performance; the CC1310 device has excellent sensitivity and robustness (selectivity and blocking) performance.

The CC1310 device is a highly integrated, true single-chip solution incorporating a complete RF system and an on-chip DC/DC converter.

Sensors can be handled in a very low-power manner by a dedicated autonomous ultra-low-power MCU that can be configured to handle analog and digital sensors; thus the main MCU (Arm® Cortex®-M3) can maximize sleep time.

The power and clock management and radio systems of the CC1310 device require specific configuration and handling by software to operate correctly, which has been implemented in the TI-RTOS. TI recommends using this software framework for all application development on the device. The complete TI-RTOS and device drivers are offered free of charge in source code.

CC1190 Description

CC1190 is a cost-effective and high-performance RF Front End for low-power and low-voltage wireless applications at 850 - 950 MHz.

CC1190 is a range extender for the sub-1 GHz low-power RF transceivers, transmitters, and System-on-Chip devices from Texas Instruments.

CC1190 integrates a power amplifier (PA), a low-noise amplifier (LNA), switches, and RF matching for the design of a high-performance wireless systems.

CC1190 increases the link budget by providing a power amplifier for increased output power, and an LNA with low noise figure for improved receiver sensitivity.

How to test N620PA module

Take the supporting base plate of Heyan technology as an example:

The bottom board of N620PA is T532AP, which integrates USB to serial chip, led, button, burning port and module card port. As shown in the figure:

CC1310 Module,CC1310 Module test

N620PA secondary development method

The CC1310 module is stuck on the backplane as shown in the figure, and the IPEX is connected with the antenna. The burning port is connected with xds110 according to the silk screen printing, and then online simulation can be carried out to test the performance of the module.

N620PA Module Programming

The schematic diagram of the module base plate can be obtained from our official website.

Please contact us for specific programming information or download it from TI official website

Ordering information

N620PA-868M   CC1310+CC1190   27dbm, 860Mhz-880Mhz

N620PA-915M   CC1310+CC1190   27dbm, 910Mhz-930Mhz

Other modules

N530AS-433M   CC1310   14dbm, 410Mhz-510Mhz

N530AS-868M   CC1310   14dbm, 860Mhz-960Mhz

N532FS-433M   CC1310+PA+LNA   24dbm, 410Mhz-510Mhz

N532FS-868M   CC1310+PA+LNA    24dbm, 860Mhz-960Mhz

N532ES-433M   CC1310+PA+LNA    30dbm, 410Mhz-440Mhz

N532ES-490M   CC1310+PA+LNA    30dbm, 470Mhz-510Mhz

N532ES-868M   CC1310+PA+LNA    30dbm, 860Mhz-880Mhz

N532ES-915M   CC1310+PA+LNA    30dbm, 910Mhz-930Mhz

Other Dongle USB

N534AP-433M   CC1310   14dbm, 410Mhz-510Mhz

N534AP-868M   CC1310   14dbm, 860Mhz-960Mhz

Files download

N620PA Software code example‍            Download N620PA datasheet            Download CC1310 datasheet

N620PA cc1310 cc1190 27dbm, 868M, 915M.pdf
N534 CC1310 uart RF dongle.pdf
N530AS CC1310 Module 14dbm.pdf
N532ES CC1310 PALNA Module,30dbm.pdf
N532FS CC1310 PA Module,24dbm.pdf
